Camera IP Hikvision 2MP DS-2CD8320GO-I – Thông số kỹ thuật
|
Camera |
|
| Image Sensor | 1/2.8″ progressive scan CMOS |
| Min. Illumination | Color: 0.01 Lux @(F1.2, AGC ON), 0.028Lux @(F2.0, AGC ON);
B/W: 0.001 Lux @(F1.2, AGC ON), 0.0028 Lux @(F2.0, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100, 000 s |
| Slow Shutter | Yes |
| Day & Night | IR cut filter |
| Digital Noise Reduction | 3D DNR |
| WDR | Digital WDR |
| Angle Adjustment | Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360° |
| Lens | |
| Focal Length | 2.8, 4, 6 mm |
| Aperture | F2.0 |
| Focus | No |
| FOV | 2.8 mm @F2.0, horizontal FOV 114°, vertical FOV 62°, diagonal FOV: 135°
4 mm @F2.0, horizontal FOV 87°, vertical FOV 48°, diagonal FOV: 102° 6 mm @F2.0, horizontal FOV 58°, vertical FOV 32°, diagonal FOV: 75° |
| IR | |
| IR Range | 2.8/4 mm: up to 30 m
6 mm: up to 35 m |
| Compression Standard | |
| Video Compression | Main stream: H.264
Sub-stream: H.264/MJPEG |
| H.264 Type | Baseline Profile/Main Profile |
| H.264+ | Main stream supports |
| Video Bit Rate | 32 Kbps to 8 Mbps |
|
Image |
|
| Max. Resolution | 1920 × 1080 |
| Main Stream
Max. Frame Rate |
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-stream
Max. Frame Rate |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Image Enhancement | BLC, 3D DNR |
| Image Settings | Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Day/Night Switch | Day, Night, Auto, Scheduled |
|
Network |
|
| Alarm Trigger | Motion detection, video tampering alarm, illegal login |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
|
General Function |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark |
|
Interface |
|
| Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| General | |
|
Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing) |
|
Power Supply |
12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3) |
|
Power Consumption and Current |
12 VDC, 0.4 A, max. 5 W; PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.1 A, max. 6 W |
|
Dimensions |
71.36 mm × 66.75 mm × 192.76 mm |
