Image Sensor |
1/2.8″ progressive scan CMOS |
Min. Illumination |
Color: 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR |
Shutter Speed |
1/3 s to 1/100, 000 s, support slow shutter |
Lens |
2.8 mm @F2.0, horizontal field of view 95°, 4 mm @F2.0, horizontal field of view 83.6°
6 mm @F2.0, horizontal field of view 55° |
Lens Mount |
M12 |
Day &Night |
IR cut filter with auto switch |
3-Axis Adjustment |
Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360° |
DNR (Digital Noise Reduction) |
3D DNR |
WDR (Wide Dynamic Range) |
Digital WDR |
Compression Standard |
|
Video Compression |
Main stream: H.264+/H.264
Sub stream: H.264/MJPEG |
H.264 Type |
Baseline Profile/Main Profile |
Video Bit Rate |
32 Kbps to 8 Mbps |
|
Max. Resolution |
1920 × 1080 |
Main Stream
Max. Frame Rate |
50Hz: 25fps @(1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps @(1920 × 1080, 1280 × 960, 1280 × 720) |
Sub-stream
Max. Frame Rate |
50Hz: 25fps @(704 × 576, 640 × 480, 352 × 288, 320 × 240)
60Hz: 30fps @(704 × 480, 640 × 480, 352 × 240, 320 × 240) |
Image Settings |
Brightness, saturation, contrast, sharpness are adjustable via web browser or client software |
Day/Night Switch |
Support auto, scheduled |
Others |
Mirror, BLC (area configurable), region of interest (support 1 fixed region) |
Network
|
Network Storage |
NAS (NFS, SMB/CIFS) |
Detections |
Motion Detection |
Alarms |
Video tampering, network disconnected, IP address conflicted |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Standard |
ONVIF (PROFILE S, PROFILE G), ISAPI |
General Function
|
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
|
Interface
|
|
Communication Interface |
1 RJ45 10M/100M self-adaptive Ethernet port |
General |
Operating Conditions
|
-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
|
Power Supply
|
12 VDC ± 25%, PoE (802.3af)
|
Power Consumption
|
Max. 4 W/6 W (PoE)
|
Ingress Protection
|
IP67
|
IR Range
|
Up to 30 m
|
Dimensions
|
Φ 85.5 mm × 70 mm (3.38″ × 2.76″)
|
Weight
|
350 g (0.77 lb.)
|
